Volume Control and Specialty  Control Dampers
VD-1330 - Class I
  • Class I High Performance
  • Very tight closure and high pressures or velocities.
VD-1330 - Class II
  • Class II Performance Blades
  • Tight closure and lower pressures or velocities.
VD-1320 - Class III
  • Class III Standard Blades
  • Normal shut-off in return air or balancing applications - not for outside air.
VD-1250 Aluminum Extruded Airfoil Shape
  • Designed for tight shutoff.
VD-1250 Thermal Extruded Airfoil Shape
  • Designed for tight shutoff.
VD-1640 Stainless Steel
  • Designed for tight shutoff

Balancing Dampers
BD-1300
  • Dampers balance air flow in commercial or light industrial applications. Balancing dampers have no seals so they are not rated for tight shut-off. Johnson Controls offers a 3-year warranty on materials and workmanship.
Round Dampers
Balancing RB-2000
  • Balancing without Seals
  • Use in balancing air flow in dynamic HVAC systems. Available with or without factory-installed manual locking quadrant.
Control RC-2000
  • Control with Seals
  • Use as a low leakage control damper in HVAC systems. Available with or without factory-installed actuator.
Fire RF-2000
  • Fire
  • Designed to prevent the spread of fire with a 1-1/2 hour fire rating in a dynamic HVAC system during life safety situations.
Smoke (Class I) - RS-2000
  • Smoke
  • Designed to prevent the spread of smoke in a dynamic HVAC system during life safety situations.
Combination - RT-2000
  • Combination Fire/Smoke
  • Designed to prevent the spread of smoke and with spread of fire with a 1-1/2 hour fire rating in a dynamic HVAC system during life safety situations.
Zone Dampers
ZD-1800
  • Zone dampers for residential, light industrial, commercial applications.  Our zone dampers are gear driven, providing less friction and low torque. Factory assembled and tested.
  • All zone dampers come with 18-gauge Triple V opposed blades with no bearing and no seals. Your choice of actuator or no actuator.
Fire Dampers
FD-1300 (Airfoil)
FD-1600 (Triple V)
  • The fire damper is a two-position device intended to restrict the spread of fire in HVAC systems in the event of a fire, the fire damper automatically closes tight and stays closed, even when the fan is still running.
  • When the  FUSIBLE LINK  temperature reaches 165°F,  212°F or 285°F (depending on model selected), the link releases a high-torque spring and BLADES SLAM SHUT.

Smoke Dampers
SD-1630 Class I - Electric
SD-1630 Class I - Pneumatic
SD-1620 - Class II - Electric
SD-1620 - Class II - Pneumatic
  • Two-Position or Modulating Dampers
  • Restricts the spread of smoke in HVAC systems that are designed to be automatically shut down in the event of a fire. Or controls the movement of smoke within a building when the HVAC system is operational in engineered smoke control systems.
  • Class I Airfoil or Class II Triple V blades available, along with your choice of an electric or pneumatic actuator
Combination Fire/Smoke Dampers
FS-1620 Class II
FS-1630 Class I
  • Combination dampers restrict the spread of fire and smoke in HVAC systems. The fire and smoke ratings are listed below.
  • Fire - UL 555 1-1/2 hour fire-rated
  • Smoke - UL 555S Class II leakage-rated and UL-555S Class
