    BBC-SD - BACnet Building Controller Small Display
    BBC-SD | SD-Pro Software | Downloads & Extras



    OVERVIEW
    The BACnet Building Controller Small Display (BBC-SD) is a compact, addressable network display device for MS/TP based BACnet networks. It enables users to quickly monitor their system, and easily make changes to the way their building is controlled. The wall mounted BBC-SD has a touch-screen operator interface with permission based menu icons, allowing simple navigation to read and write BACnet values, view alarms, grouped data, and point descriptions. The BBC-SD is easily configured via the Windowsฎ-based BBC-SD-ProTM Configuration Utility.
    FEATURES
    • Full Color TFT-based Touch Screen Local User Interface for display and modification
    • Multi-tiered icon driven screen navigation
    • Able to automatically display and modify up to 150 stored BACnet object properties
    • Multi-level numeric password-based access
    • Flash program upgradeable through use of standard SD/MMC card port
    • Conforms to BACnet MS/TP LAN Standard
    • Token and network activity icons
    • 50 customizable 24-character menu text headers
    • Advanced MS/TP diagnostics utilities
    • Up to 16 linked BACnet schedules and/or calendars
    • Manually address, view and modify any primitive data points on the local MS/TP network




    OVERVIEW
    SD-Pro is a PC-based configuration environment used to setup and configure the operational parameters of the BBC-SD. Through the use of this software users can define key data from BACnet MS/TP units which will be displayed on the screen for monitoring and modification. Once all configuration parameters have been defined, a configuration file can be generated (saved) and transported to the BBC-SD through the use of its local SD-card socket or via BACnet File Services.



    BBC-SD Overview (.exe)
    To view, click and select save or right-click and select Save Target As...
    BBC-SD Datasheet
    BBC-SD User Manual
    SD-Pro Demo Software (57.0 MB)
    Save function requires USB Key
    BBC-SD Mounting Template
    BBC-SD Protocol Implementation Conformance Statement (PICS)
